AISC-1210-xxx

30332 Esperanza, Rancho Santa Margarita, California92688

Revised: 12.28.12

Visit www.abracon.com for Terms & Conditions of Sale

SMD CERAMIC WIRE-WOUND INDUCTORS

FEATURES:

APPLICATIONS:

ELECTRICAL SPECIFICATIONS:

Compliant

PARAMETERS

ABRACON P/N:

AISC-01210-xxx Series

Operating temperature

-40°C to + 125°C

Storage temperature

PARAMETERS

3.65 x 2.95 x 2.70mm

• Exceptional high Q and SRF for high frequency applications

• Low DCR and high rated current

• Tight tolerances, many values at 2%

• Small size suitable for surface mounting

• Widely used in mobile phones

• Bluetooth, W-LAN. Broadband Network

• High Frequency Communication Circuits

• Camcorders, TVs and other electronic devices

Part Number

AISC-1210-

Inductance

Inductance

Tolerance

Min.

Quality

Factor

L/Q Test

Freq.

Max. DC

Resistance

Max. Rated

Current

Min. Self-resonant

Frequency

Units

nH

-

-

MHz

Ω

mA

MHz

Symbol

L

-

Q

Freq.

DCR

Ir

S.R.F

AISC-1210-3N9

3.9

J, K

30

100/300

0.05

1000

6000

AISC-1210-4N7

4.7

J, K

30

100/300

0.065

1000

5800

AISC-1210-8N2

8.2

J, K

30

100/300

0.07

1000

5500

AISC-1210-10N

10

G, J, K

40

100/300

0.08

1000

4000

AISC-1210-12N

12

G, J, K

40

100/300

0.08

1000

3200

AISC-1210-15N

15

G, J, K

40

100/300

0.10

1000

3200

AISC-1210-18N

18

G, J, K

50

100/300

0.10

1000

2800

AISC-1210-22N

22

G, J, K

50

100/300

0.10

1000

2200

AISC-1210-27N

27

G, J, K

50

100/300

0.11

1000

1800

AISC-1210-33N

33

G, J, K

55

100/300

0.11

1000

1800

AISC-1210-39N

39

G, J, K

55

100/300

0.12

1000

1500

AISC-1210-43N

43

G, J, K

55

100/300

0.12

1000

1500

AISC-1210-47N

47

G, J, K

55

100/300

0.13

1000

1500

AISC-1210-56N

56

G, J, K

55

100/300

0.14

1000

1450

AISC-1210-68N

68

G, J, K

55

100/300

0.15

900

1200

AISC-1210-82N

82

G, J, K

55

100/300

0.20

900

1000

AISC-1210-R10

100

G, J, K

55

100/300

0.20

850

900

AISC-1210-R12

120

G, J, K

60

100/300

0.25

800

800

AISC-1210-R15

150

G, J, K

60

100/300

0.25

750

700

AISC-1210-R18

180

G, J, K

60

50/300

0.30

700

650

AISC-1210-R22

220

G, J, K

60

50/300

0.40

770

650

AISC-1210-R27

270

G, J, K

40

50/300

0.40

630

580

AISC-1210-R33

330

G, J, K

45

50/150

0.58

590

580

AISC-1210-R39

390

G, J, K

45

50/150

0.58

530

510

AISC-1210-R47

470

G, J, K

45

50/150

0.80

490

480

AISC-1210-R56

560

G, J, K

45

35/150

1.10

460

420

-10ºC to +40ºC, 70% RH max.
