AISC-1210-xxx

30332 Esperanza, Rancho Santa Margarita, California92688

Revised: 12.28.12

Visit www.abracon.com for Terms & Conditions of Sale

SMD CERAMIC WIRE-WOUND INDUCTORS

Compliant

3.65 x 2.95 x 2.70mm

Key Electrical Specifications (Con’d)

Part Number

AISC-0603-

Inductance

Tolerance

Min.

Quality

Factor

L/Q Test

Freq.

Max. DC

Resistance

Max. Rated

Current

Min. Self-resonant

Frequency

Units

nH

-

-

MHz

Ω

mA

MHz

Symbol

L

-

Q

Freq.

DCR

Ir

S.R.F

AISC-1210-R68

680

G, J, K

45

35/150

1.20

430

400

AISC-1210-R82

820

G, J, K

45

35/150

1.82

400

370

AISC-1210-1R0

1000

G, J, K

45

35/150

1.85

320

340

AISC-1210-1R2

1200

G, J, K

35

35/150

1.87

300

220

AISC-1210-1R5

1500

G, J, K

20

7.9/50

1.95

310

160

AISC-1210-1R8

1800

G, J, K

30

7.9/50

2.25

310

160

AISC-1210-2R2

2200

G, J, K

25

7.9/50

2.41

310

130

AISC-1210-2R7

2700

G, J, K

25

7.9/50

2.85

300

110

AISC-1210-3R0

3000

G, J, K

20

7.9/25

3.12

300

110

AISC-1210-3R9

3900

G, J, K

20

7.9/25

3.60

290

60

AISC-1210-4R7

4700

G, J, K

20

7.9/25

4.00

280

60

AISC-1210-5R6

5600

G, J, K

15

7.9/25

5.00

250

50

AISC-1210-6R8

6800

G, J, K

15

7.9/7.9

8.00

230

40

AISC-1210-8R6

8600

G, J, K

15

7.9/7.9

9.00

200

40

Test Conditions and Equipemt

b. Relative Humidity: 65%±20%

c. Air Pressure: 86KPa to 106KPa

Inductance (L): Agilent4287A+Agilent16197A or equivalent, -13dBm or 10mA

Direct Current Resistance (DCR): HIOKI 3540 or equivalent

Q Factor (Q): Agilent4287A+Agilent16197A or equivalent, -13dBm or 10mA

Self-Resonant Frequency (SRF): Agilent4991B+Agilent16197A and HP 8753E or equivalent, -20dBm or 50mV

chip initial surface temperature (Ta)

ELECTRICAL CHARACTERISTICS CURVES
