ASPI-4030S

30332 Esperanza, Rancho Santa Margarita, California92688

Revised: 03.09.13

Visit www.abracon.com for Terms & Conditions of Sale

Wire Wound Magnetically Shielded SMD Power Inductor

:

4.0 x 4.0 x 3.0 mm

ABRACON IS

ISO9001:2008

CERTIFIED

PART IDENTIFICATION:

ELECTRICAL CHARACTERISTICS CURVES

Recommended Land Pattern

Dimensions: mm

OUTLINE DIMENSIONS:

*M for 3.3µH~120µH

*N for 0.91µH~2.2µH

:

ASPI-4030S -

-

Inductance Code

Please refer to the

table above

Tolerance

M: ±20% *

N: ±30% *

Packaging

T: Tape and Reel

(2kpcs / reel)

b

b

a

A

B

C Max.

D

E

F

a Typ.

b Typ.

c Typ.

4.0±0.2

4.0±0.2

3.0

3.3±0.2

0.95±0.2

2.1±0.2

1.9

1.1

3.4
