B（Gull wing）

C（Through hole pins）

B（Gull wing）

C（Through hole pins）

B（Gull wing）

C（Through hole pins）

B（Gull wing）

C（Through hole pins）

B（Gull wing）

C（Through hole pins）

C（Through hole pins）

C（Through hole pins）

Taping

Magazine

Taping

Magazine

Taping

Magazine

Taping

Magazine

Taping

Magazine

Magazine

Magazine

2

3

Side setting

Side setting

Top setting

No function

Single

No function

Single

Double

No function

Double

No. of contacts

Setting position

Self-return function

Shape of terminal

Form of packaging

Part number

Pieces in package

CSS-1210TB

CSS-1210MC

CSS-1211TB

CSS-1211MC

CSS-1310TB

CSS-1310MC

CSS-1311TB

CSS-1311MC

CSS-1312TB

CSS-1312MC

CSS-1300MC

CSS-1302MC

1,900 pcs./reel

53 pcs./stick

1,900 pcs./reel

53 pcs./stick

1,900 pcs./reel

38 pcs./stick

1,900 pcs./reel

38 pcs./stick

1,900 pcs./reel

38 pcs./stick

38 pcs./stick

38 pcs./stick

CSS

COMPACT SLIDE SWITCHES

No. of positions

Stroke

Operating force

Stop strength

Solderability

Soldering heat

Shear (Adhesion)

Substrate bending

Pull-off strength

2, 3

2 mm

1 ~ 3.5 N {0.1 ~ 0.36 kgf}

10 N {1.02 kgf} 15 s

245

± 3 °C 2 ~ 3 s

Sn-3Ag-0.5Cu

5 N {0.5 kgf} 10 s

Width 90 mm, bend 3 mm, 5 s, 1 time

5 N {0.5 kgf} 10 s

Vibration

Shock

Load life

Humidity

High temp. exposure

Low temp. exposure

Thermal shock

Amplitude 1.5 mm or Acceleration 98 m/s

10-500-10 Hz, 3 directions for 10 cycles each

490 m/s

Continuous load 10000 cycles,

DC12

± 0.5 V, 100 ± 10 mA

85 °C, 96 h, No load

−40 °C, 96 h, No load

−40 (0.5 h) ~ 85 °C (0.5 h), 5 cycles

{ } : Reference only

Reflow

：250 ~ 255 °C (Peak temperature)

（Please refer to the profile below）

Manual soldering

：350

± 10 °C, 3 ~ 4 s

Reflow : two times maximum

Peak : 250

Over 230 C

Pre Heating Zone

180 C

(C)

250

200

150

100

50

150 C

90 30 s

30 10 s

Soldering Zone

Heating time

C

+5

0

Operating temp. range

Storage temp. range

Sealing

Net weight

− 20 ~ 70 °C

− 40 ~ 85 °C

Non washable

Approx. 0.11 g (CSS-12), Approx. 0.15 g (CSS-13)

Contact rating

Contact timing

Contact resistance

Insulation resistance

Dielectric strength

Non-switching : DC50 V 100 mA

Switching : DC12 V 100 mA

Minimum : DC20 mV 1 μA

Non-shorting

70 m

Ω maximum

100 M

Ω minimum (DC 500 V)

AC500 V 60 s

40 °C, Relative humidity 90 ~ 95 %, 240 h, No load
