3.1.2.1

On-chip Debugger

The 8051 works with a high‐performance “Hardware Assisted Debugger” which manages the

communication between the core and the software.

3.1.2.2

UART / FTDI UART

There are two UARTs in the system – one designed by FTDI and the second incorporated within the 8051

core. The 8051 UART has a maximum baud rate of up to 60kbps. The FTDI UART gives speeds up to

3Mbps.

When the data and control bus are configured in UART mode, the interface implements a standard

asynchronous serial UART port with full modem control. The UART can support baud rates from 183 baud

to 3 Mbaud. The maximum UART speed is limited by the CPU clock. The following maximum UART speed

applies:

CPU Frequency

Maximum UART Speed

48 MHz

3 Mbaud

24 MHz

3 Mbaud

12 MHz

1.5 Mbaud

3.2 Functional Block Descriptions

The following paragraphs detail each function within the FT51A. Please refer to the block diagram shown

in Figure 3-1 – FT51A Block Diagram.

3.2.1

8051 Ports 0 - 3

The 8051 core has four 8-bit bidirectional ports: P0, P1, P2 and P3. These ports can be fully or partially

mapped to external pins on the AIO and DIO bus. Firmware can change the pin mapping through IOMUX

programming. Table 3-1 shows the default pin mapping for all the 4 ports on the LQFP44 and WQFN48

packages.

PIN

TYPE

DESCRIPTION

AIO7 - AIO0

Input / output

P0.7 – P0.0

AIO15 - AIO8

Input / output

P2.7 – P2.0

DIO7 - DIO0

Input / output

P1.7 – P1.0

DIO15 - DIO8

Input / output

P3.7 – P3.0

Table 3-1 – 8051 Ports

3.2.2

Timers and Watchdog

Apart from standard 8051 timers the FT51A has four general purpose 16-bit timers A, B, C and D. A 32-

bit watchdog timer is also provided.
