ADA4528-2ARMZ-R7 datasheet(16/28 Pages) AD

16 / 28 page

ADA4528-1/ADA4528-2

Data Sheet

Rev. D | Page 16 of 28

TIME (10µs/DIV)

0.5

–0.5

–1

VSY = ±1.25V

AV = –10

VIN = 187.5mV

RL = 10kΩ

CL = 100pF

INPUT

OUTPUT

Figure 44. Positive Overload Recovery

TIME (10µs/DIV)

0.5

–0.5

–2

–1

VSY = ±1.25V

AV = –10

VIN = 187.5mV

RL = 10kΩ

CL = 100pF

INPUT

OUTPUT

Figure 45. Negative Overload Recovery

TIME (10µs/DIV)

VSY = 2.5V

RL = 10kΩ

CL = 100pF

DUT AV = –1

INPUT

+7.5mV

–7.5mV

OUTPUT

ERROR BAND

POST GAIN = 5

Figure 46. Positive Settling Time to 0.1%

TIME (10µs/DIV)

0.5

–0.5

–1

VSY = ±2.5V

AV = –10

VIN = 375mV

RL = 10kΩ

CL = 100pF

INPUT

OUTPUT

Figure 47. Positive Overload Recovery

TIME (10µs/DIV)

0.5

–0.5

–3

–2

–1

VSY = ±2.5V

AV = –10

VIN = 375mV

RL = 10kΩ

CL = 100pF

INPUT

OUTPUT

Figure 48. Negative Overload Recovery

TIME (10µs/DIV)

VSY = 5V

RL = 10kΩ

CL = 100pF

DUT AV = –1

INPUT

+20mV

–20mV

OUTPUT

ERROR BAND

POST GAIN = 5

Figure 49. Positive Settling Time to 0.1%
