18 / 28 page

ADA4528-1/ADA4528-2

Data Sheet

Rev. D | Page 18 of 28

TIME (1s/DIV)

VSY = 2.5V

VCM = VSY/2

AV = 100

Figure 56. 0.1 Hz to 10 Hz Noise

0.001

0.01

0.1

0.001

0.01

0.1

AMPLITUDE (V p-p)

VSY = 2.5V

AV = 1

f = 1kHz

RL = 10kΩ

Figure 57. THD + N vs. Amplitude

0.001

0.01

0.1

100

10k

100k

FREQUENCY (Hz)

VSY = 2.5V

AV = 1

RL = 10kΩ

80kHz LOW-PASS FILTER

VIN = 2V p-p

Figure 58. THD + N vs. Frequency

TIME (1s/DIV)

VSY = 5V

VCM = VSY/2

AV = 100

Figure 59. 0.1 Hz to 10 Hz Noise

0.001

0.01

0.1

0.001

0.01

0.1

AMPLITUDE (V p-p)

VSY = 5V

f = 1kHz

RL = 10kΩ

AV = 1

Figure 60. THD + N vs. Amplitude

0.001

0.01

0.1

100

10k

100k

FREQUENCY (Hz)

VSY = 5V

AV = 1

RL = 10kΩ

80kHz LOW-PASS FILTER

VIN = 2V p-p

Figure 61. THD + N vs. Frequency
