ADA4895-1/ADA4895-2

Data Sheet

TYPICAL PERFORMANCE CHARACTERISTICS

TA = 25°C, VS = ±2.5 V, G = +10, RF = 249 Ω, RL = 1 kΩ to midsupply, unless otherwise noted.

–5

–4

–3

–2

–1

0.1

100

1000

FREQUENCY (MHz)

VOUT = 200mV p-p

VS = ±5.0V

VS = ±1.5V

VS = ±2.5V

Figure 8. Small Signal Frequency Response vs. Supply Voltage

–10

–8

–6

–4

–2

0.1

100

1000

FREQUENCY (MHz)

G = –10

G = +10

RF = 1kΩ

VOUT = 200mV p-p

G = –20

Figure 9. Small Signal Frequency Response vs. Gain

–5

–4

–3

–2

–1

0.1

100

1000

FREQUENCY (MHz)

VOUT = 200mV p-p

+25°C

+125°C

–40°C

Figure 10. Small Signal Frequency Response vs. Temperature

–5

–4

–3

–2

–1

0.1

100

1000

FREQUENCY (MHz)

VOUT = 2V p-p

VS = ±1.5V

VS = ±5.0V

VS = ±2.5V

Figure 11. Large Signal Frequency Response vs. Supply Voltage

–5

–4

–3

–2

–1

0.1

100

1000

FREQUENCY (MHz)

RF = 1kΩ

VOUT = 2V p-p

G = +10

G = –10

G = –20

Figure 12. Large Signal Frequency Response vs. Gain

–5

–4

–3

–2

–1

0.1

100

1000

FREQUENCY (MHz)

VOUT = 100mV p-p

VOUT = 400mV p-p

VOUT = 2V p-p

VOUT = 1V p-p

Figure 13. Frequency Response for Various Output Voltages
