FT234XD USB TO BASIC UART IC

Version 1.2

Document No.: FT_000753 Clearance No.: FTDI#324

1 Typical Applications



USB to RS232/RS422/RS485 Converters



Upgrading Legacy Peripherals to USB



Utilising USB to add system modularity



Incorporate USB interface to enable PC

transfers for development system

communication



Cellular and Cordless Phone USB data transfer

cables and interfaces



Interfacing MCU/PLD/FPGA based designs to

add USB connectivity



USB Audio and Low Bandwidth Video data

transfer



USB Smart Card Readers



USB Instrumentation



USB Industrial Control



USB FLASH Card Reader and Writers



Set Top Box PC - USB interface



USB Wireless Modems



USB Bar Code Readers



USB dongle implementations for Software/

Hardware Encryption and Wireless Modules



Detection of dedicated charging port for battery

charging at higher supply currents.

1.1 Driver Support

Royalty free VIRTUAL COM PORT

(VCP) DRIVERS for...



Windows 10 32,64-bit



Windows 8/8.1 32,64-bit



Windows 7 32,64-bit



Windows Vista and Vista 64-bit



Windows XP and XP 64-bit



Windows 98, 98SE, ME, 2000, Server 2003, XP,

Server 2008 and server 2012 R2



Windows XP Embedded



Windows CE 4.2, 5.0 and 6.0



Mac OS 8/9, OS-X



Linux 2.4 and greater

Royalty free D2XX Direct Drivers

(USB Drivers + DLL S/W Interface)



Windows 10 32,64-bit



Windows 8/8.1 32,64-bit



Windows 7 32,64-bit



Windows Vista and Vista 64-bit



Windows XP and XP 64-bit



Windows 98, 98SE, ME, 2000, Server 2003, XP,

Server 2008 and server 2012 R2



Windows XP Embedded



Windows CE 4.2, 5.0 and 6.0



Linux 2.4 and greater



Android(J2xx)

The drivers listed above are all available to download for free from FTDI website (www.ftdichip.com).

Various 3rd party drivers are also available for other operating systems - see FTDI website

(www.ftdichip.com) for details.

For driver installation, please refer to http://www.ftdichip.com/Documents/InstallGuides.htm

1.2 Part Numbers

Part Number

Package

FT234XD-x

12 Pin DFN

Note: Packing codes for x is:

- R: Taped and Reel - 5,000pcs per reel.

- T: Tray packing - 490pcs per tray.
