RELI-DA01/R

Series

LIGHTLINE

AC/DC-Converter

Package Style

Indicator LED

flashes with

DALI signal

ON / OFF

PWM / DC

By internal switch

ON: PWM 10V (Default active high)

OFF: DC 1-10V (Default DC)

DC 0-10V (software control)

Delivery setting:

Output signal:

DC 1-10V

Dimming curve: Logarithmic PWM active high

Refer to instruction sheet for DALI commands for alternate settings (linear dimming curve, DC 0-10V, PWM active low, Independent Relay control)

40

130

150

4

28

tc

65

Dimensions

www.recom-power.com

L-75

REV: 0/2015
