Industrial Layer-3 12-port managed Gigabit PoE Ethernet switch

with 8x10/100/1000Base-T(X) P.S.E. and 4x100/1000Base-X, SFP

socket

IGPS-R9084GP

▪

Supports Layer 3 routing, RIP and static routing function

▪

Support O-Ring (recovery time < 30ms over 250 units of connection) and

MSTP(RSTP/STP compatible) for Ethernet Redundancy

▪

O-Chain allow multiple redundant network rings

▪

function

▪

8 port P.S.E. fully compliant with IEEE802.3at standard, provide up to 30

Watts per port

▪

Support PoE scheduled configuration and PoE auto-ping check function

▪

Support IEEE 1588v2 clock synchronization

▪

Support IPV6 new internet protocol version

▪

Support Modbus TCP protocol

▪

Support IEEE 802.3az Energy-Efficient Ethernet technology

▪

Provided HTTPS/SSH protocol to enhance network security

▪

Support SMTP client and NTP server protocol

▪

Support IP-based bandwidth management

▪

Support application-based QoS management

▪

Support Device Binding security function

▪

Support DOS/DDOS auto prevention

▪

IGMP v2/v3 (IGMP snooping support) for filtering multicast

traffic

▪

Support SNMP v1/v2c/v3 & RMON & 802.1Q VLAN Network Management

▪

Support ACL, TACACS+ and 802.1x User Authentication

for security

▪

Supports 9.6K Bytes Jumbo Frame

▪

Multiple notification for warning of unexpected event

▪

Supports backup unit device DBU-01 for quickly backup/restore

configuration

▪

Web-based ,Telnet, Console (CLI), and Windows utility (Open-Vision)

configuration

▪

Support LLDP Protocol

▪

Rigid IP-30 housing design

▪

DIN-Rail and wall mounting enabled

IGPS-R9084GP is Layer-3 managed redundant ring PoE Ethernet switch with 8x10/100/1000Base-T(X) P.S.E. ports and 4x100/1000Base-X SFP ports. The

IGPS-R9084GP supports Layer-3 routing for better network performance on large-scale LANs into multiple subnets to support long-haul and EMI immunity

communications. The hardware Layer-3 switch is optimized to transmit data as fast as Layer-2 switches. The switch support Ethernet Redundancy protocol, O-Ring

(recovery time < 30ms over 250 units of connection) and MSTP (RSTP/STP compatible) can protect your mission-critical applications from network interruptions or

temporary malfunctions with its fast recovery technology. IGPS-R9084GP also support Power over Ethernet, a system to transmit electrical power up to 30 watts,

along with data, to remote devices over standard twisted-pair cable in an Ethernet network. Each IGPS-R9084GP switch has 8x10/100/1000Base-T(X) P.S.E. (Power

Sourcing Equipment) ports. P.S.E. is a device (switch or hub for instance) that will provide power in a PoE connection. And support wide operating temperature

from -40 to 75

configuration. Therefore, the switch is one of the most reliable choice for highly-managed and Fiber Ethernet application.

Introduction

Features

O-Ring

Industrial Ethernet Switch DIN-Rail Managed Gigabit PoE Ethernet Switch

P.S.E

Full Gigabit

v1.0a / Feb, 2013

▪

O-Ring : O-Ring is ORing's proprietary redundant ring technology, with recovery time of less 30 milliseconds and up to 250 nodes. The O-Ring redundant ring

technology can protect mission-critical application from network interruptions or temporary malfunction with its fast recover technology.

IGPS-R9084GP

*NOTE: This function is available by request only
