Designed for Rugged Excellence

v1.0a Oct, 2014

Industrial Ethernet Switch DIN-Rail Managed Gigabit Ethernet Switch

ORing Switch Model

IGPS-R9084GP

Physical Ports

10/100/1000Base-T(X) Ports in RJ45 Auto MDI/MDIX

8

100/1000Base-X with SFP port

4

Technology

Ethernet Standards

IEEE 802.3 for 10Base-T

IEEE 802.3u for 100Base-TX and 100Base-FX

IEEE 802.3ab for 1000Base-T

IEEE 802.z for 1000Base-X

IEEE 802.3x for Flow control

IEEE 802.3ad for LACP (Link Aggregation Control Protocol )

IEEE 802.1p for COS (Class of Service)

IEEE 802.1Q for VLAN Tagging

IEEE 802.1w for RSTP (Rapid Spanning Tree Protocol)

IEEE 802.1s for MSTP (Multiple Spanning Tree Protocol)

IEEE 802.1x for Authentication

IEEE 802.1AB for LLDP (Link Layer Discovery Protocol)

IEEE 802.3at PoE specification (up to 30 Watts per port for P.S.E.)

MAC Table

8K

Packet Buffer

32Mbits

Flash Memorry

128Mbits

DRAM Size

1Gbits

Priority Queues

8

Processing

Store-and-Forward

Switch Properties

Switching latency: 7 μs

Switching bandwidth: 24Gbps

Max. Number of Available VLANs : 4095

VLAN ID Range : 1 to 4094

IGMP multicast groups: 256 for each VLAN

Port rate limiting: User Define

Jumbo frame

Up to 9.6K Bytes

Security Features

Device Binding security feature

Enable/disable ports, MAC based port security

Port based network access control (802.1x)

Single 802.1x and Multiple 802.1x

MAC-based authentication

QoS assignment

Guest VLAN

MAC address limit

TACACS+

Specifications

PoE Pin Definition

10/100Base-T(X) P.S.E. RJ-45 Port

RJ-45 Pin Definition

Pin No.

Description

#1

TD+ with PoE Power input +

#2

TD- with PoE Power input +

#3

RD+ with PoE Power input -

#6

RD- with PoE Power input -

1000Base-T P.S.E. RJ-45 Port

RJ-45 Pin Definition

Pin No.

Description

#1

BI_DA+ with PoE Power input +

#2

BI_DA- with PoE Power input +

#3

BI_DB+ with PoE Power input -

#4

BI_DC+

#5

BI_DC-

#6

BI_DB- with PoE Power input -

#7

BI_DD+

#8

BI_DD-
