Designed for Rugged Excellence

Industrial Layer-3 20-port managed Gigabit Ethernet switch

with 8x10/100/1000Base-T(X) ports and 12x100/1000Base-X,

SFP socket

IGS-R9812GP

▪

Supports Layer 3 routing, RIP and static routing function

▪

Supports O-Ring (recovery time < 30ms over 250 units of connection) and

MSTP(RSTP/STP compatible) for Ethernet Redundancy

▪

O-Chain allow multiple redundant network rings

▪

▪

Supports IEEE 1588v2 clock synchronization

▪

Supports IPV6 new internet protocol version

▪

Supports Modbus TCP protocol

▪

Supports IEEE 802.3az Energy-Efficient Ethernet technology

▪

Provided HTTPS/SSH protocol to enhance network security

▪

Supports SMTP client and NTP server protocol

▪

Supports IP-based bandwidth management

▪

Supports application-based QoS management

▪

Supports Device Binding security function

▪

Supports DOS/DDOS auto prevention

▪

IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic

▪

Supports SNMP v1/v2c/v3 & RMON & 802.1Q VLAN Network Management

▪

Supports ACL, TACACS+ and 802.1x User Authentication for security

▪

Supports 9.6K Bytes Jumbo Frame

▪

Supports backup unit device DBU-01 for quickly backup/restore

configuration

▪

Multiple notification for warning of unexpected event

▪

Web-based ,Telnet, Console (CLI), and Windows utility (Open-Vision) configuration

▪

Supports LLDP Protocol

▪

Rigid IP-30 housing design

▪

DIN-Rail and wall mounting enabled

IGS-R9812GP is Layer-3 managed redundant ring Ethernet switch with 8x10/100/1000Base-T(X) ports and 12x100/1000Base-X SFP ports. The IGPS-

R9812GP supports Layer-3 routing for better network performance on large-scale LANs into multiple subnets to support long-haul and EMI immunity

communications. The hardware Layer-3 switch is optimized to transmit data as fast as Layer-2 switches. With completely support of Ethernet Redundancy

protocol, O-Ring (recovery time < 30ms over 250 units of connection) and MSTP (RSTP/STP compatible) can protect your mission-critical applications from

network interruptions or temporary malfunctions with its fast recovery technology. And support wide operating temperature from -40 to 75

can also be managed centralized and convenient by Open-Vision, as well as the Web-based interface, Telnet and console (CLI) configuration. Therefore, the

switch is one of the most reliable choice for highly-managed and Fiber Ethernet power substation and rolling stock application.

▪

O-Ring : O-Ring is ORing's proprietary redundant ring technology, with recovery time of less 30 milliseconds and up to 250 nodes. The O-Ring r

edundant ring technology can protect mission-critical application from network interruptions or temporary malfunction with its fast recover

technology.

Features

Introduction

Industrial Ethernet Switch DIN-Rail Managed Gigabit Ethernet Switch

v1.0a Oct, 2014

IGS-R9812GP

*NOTE: This function is available by request only
