Designed for Rugged Excellence

Network Redundancy

O-Ring O-Chain

RS-232 Serial Console Port

RS-232 in RJ45 connector with console cable. 115200bps, 8, N, 1

LED Indicators

Power Indicator(PWR)

Green : Power LED x 3

Ring Master Indicator (R.M.)

Green : Indicates that the system is operating in O-Ring Master mode

O-Ring Indicator (Ring)

Green : Indicates that the system operating in O-Ring mode

Green Blinking : Indicates that the Ring is broken.

Fault Indicator(Fault)

Amber : Indicate unexpected event occurred

10/100/1000Base-T(X) RJ45 Port Indicator

Green for Link/Act indicator

Dual color LED for speed indicator : Green for 1000Mbps, Amber for 100Mbps, Off-light for 10Mbps

100/1000Base-X SFP port Indicator

Green for port Link/Act.

Fault Contact

Relay

Relay output to carry capacity of 1A at 24VDC

Power

Redundant Input Power

Dual DC inputs. 12~48 VDC on 6-pin terminal block

Power Consumption (Typ.)

23 Watts

Overload Current Protection

Present

Reverse Polarity Protection

Present

Physical Characteristics

Enclosure

IP-30

Dimensions (W x D x H)

96.4 x 145.5 x 154 mm (3.8 x 5.73 x 6.06 inch)

Weight (g)

1520 g

Environmental

Storage Temperature

-40 to 85°C (-40 to 185°F)

Operating Temperature

-40 to 75°C (-40 to 167°F)

Operating Humidity

5% to 95% Non-condensing

Regulatory Approvals

EMI

FCC Part 15, CISPR (EN55022) class A

EMS

EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8,

EN61000-4-11

Shock

IEC60068-2-27

Free Fall

IEC60068-2-31

Vibration

IEC60068-2-6

Safety

EN60950-1

Warranty

5years

Available

Model

Model Name

Description

IGS-R9812GP

Industrial Layer-3 20-port managed Gigabit Ethernet switch with 8x10/100/1000Base-T(X) and 12x100/1000Base-X, SFP

socket

Packing List

‧

IGS-R9812GP

‧

DIN-Rail Kit

‧

Wall-mount Kit

‧

Console Cable

‧

ORing Tool CD

‧

Quick Installation Guide

‧

Open-Vision M500, Powerful Network Management Windows Utility Suite, 500 IP devices

‧

SFP100 series, 100Mbps SFP optical transceiver

‧

SFP1G series, 1Gbps SFP optical transceiver

‧

DR-45 series, 45W DIN-Rail power supply

‧

DR-75 series, 75W DIN-Rail power supply

‧

DR-120 series, 120W DIN-Rail power supply

IGS-R9 A BB CC

Ordering Information

Code Definition

10/100/1000Base-T(X) Port Number

100/1000Base-(F)X SFP Port Number

Additional Port Type

Option

- 08: 8 ports

- 12: 12 ports

-GP: Gigabit SFP ports

Industrial Ethernet Switch DIN-Rail Managed Gigabit Ethernet Switch

v1.0a Oct, 2014

*NOTE: This function is available by request only
