Data Sheet

ADCLK905/ADCLK907/ADCLK925

Rev. B | Page 11 of 16

58ps/DIV

Figure 19. 2.488 Gbps PRBS 223 − 1 with OC-48/STM-16 Mask,

Measured p-p Jitter 8.1 ps, Source p-p Jitter 3.5 ps

15ps/DIV

Figure 20. 9.95 Gbps PRBS 223 − 1 with OC-193/STM-64 Mask,

Measured p-p Jitter 10.5 ps, Source p-p Jitter 6.0 ps

34ps/DIV

Figure 21. 4.25 Gbps PRBS 223 − 1 with FC4250 (Optical) Mask,

Measured p-p Jitter 8.2 ps, Source p-p Jitter 3.4 ps

17ps/DIV

Figure 22. 8.50 Gbps PRBS 223 − 1 with FC8500E ABS Beta Rx Mask,

Measured p-p Jitter 10.9 ps, Source p-p Jitter 4.4 ps

58ps/DIV

Figure 23. 2.5 Gbps PRBS 223 − 1 with PCI Express 2.5 Rx Mask,

Measured p-p Jitter 8.1 ps, Source p-p Jitter 3.5 ps

29ps/DIV

Figure 24. 5.0 Gbps PRBS 223 − 1 with PCI Express 5.0 Rx Mask,

Measured p-p Jitter 8.7 ps, Source p-p Jitter 3.5 ps
