1217841 datasheet(5/9 Pages) SICK

5 / 9 page

MLG20N-2080P10501 | MLG-2 ProNet

MEASURING AUTOMATION LIGHT GRIDS

Dimensional drawing (Dimensions in mm (inch))

(1.34)

36.3 (1.43)

38.5 (1.52)

38.1 (1.50)

30.6 (1.20)

36.3 (1.43)

38.5 (1.52)

40.6 (1.60)

(1.34)

30.5

(1.2)

30.5

(1.2)

(0.59)

34 (1.34)

23.3

(0.92)

17.7

(0.70)

Receiver

Sender

Ø M12

A 1)

Beam separation 2.5 mm

62.25 (2.45)

17.15 (0.68)

Beam separation 5 mm

63.3 (2.49)

16.1 (0.63)

Beam separation 10 mm

68.3 (2.69)

16.1 (0.63)

Beam separation 20 mm

68.3 (2.69)/78.3 (3.08) 3)

16.1 (0.63)

Beam separation 25 mm

83.3 (3.28)

16.1 (0.63)

Beam separation 30 mm

88.3 (2.69)

16.1 (0.63)

Beam separation 50 mm

108.3 (4.26)

16.1 (0.63)

1) Distance: MLG-2 edge - first beam

2) Distance: MLG-2 edge - last beam

3) MLG20x-xx40: 68.3 mm

MLG20x-xx80: 78.3 mm

B 2)

① Detection height (see optical performance)

② Beam separation (RM)

③ Status indicator: green, yellow, red LEDs

④ Safty screw M4; turning moment 0,5 Nm

2019-07-19 17:41:20 | Online data sheet

Subject to change without notice

AUTOMATION LIGHT GRIDS | SICK
