MLG20N-2080P10501 | MLG-2 ProNet

MEASURING AUTOMATION LIGHT GRIDS

Connection diagram

T-piece

n

I

_

t

s

e

T

T-Junction, 5-pin

BN

WH

BU

BK

GY

Recommended accessories

Other models and accessories

www.sick.com/MLG-2_ProNet

Brief description

Type

Part no.

Terminal and alignment brackets

Bracket for external mounting of the fieldbus module, 1 x angle holder and 1 x screw

M5 x 6-8.8, Stainless steel V2A (1.4301)

BEF-WN-FBM-SET1

2082322

Adapters and distributors

SBO-02G12-SM

6029305

Plug connectors and cables

Head A: male connector, M12, 4-pin, straight, D-coded

Head B: male connector, RJ45, 8-pin, straight

Cable: Ethernet, twisted pair, PUR, halogen-free, shielded, 5 m

YM2D24-

050EA1MRJA4

6034415

Head A: male connector, M12, 4-pin, D-coded

Head B: male connector, M12, 4-pin, D-coded

Cable: Ethernet, twisted pair, PUR, halogen-free, shielded, 5 m

YM2D24-

050EA2M2D24

6034422

8
