CY8CKIT-059 PSoC® 5LP Prototyping Kit Guide, Doc. #: 001-96498 Rev. *G

Software Installation

This chapter describes the steps to install the software tools and packages on a PC for using the

PSoC 5LP Prototyping Kit. This includes the IDE on which the projects will be built and used for

programming.

2.1

Before You Begin

All Cypress software installations require administrator privileges, but these are not required to run

the software after it is installed. Close any other Cypress software that is currently running before

installing the kit software.

Note: By default, the kit contents are installed in the C:\Program Files\Cypress folder, for a

32-bit machine and C:\Program Files (x86)\Cypress, for a 64-bit machine. This directory will

contain the kit code examples. To open these code examples, it is recommended to use the

procedure described in the Code Examples chapter on page 31. This procedure will create an

editable copy of the code example in a path that you chose so that the original installed code

examples will not be modified.

2.2

Install Software

Follow these steps to install the PSoC 5LP Prototyping Kit software:

1. Download the PSoC 5LP Prototyping Kit software from www.cypress.com/CY8CKIT-059. The kit

software is available in three formats for download.

a. CY8CKIT-059 Kit Setup: This installation package contains the files related to the kit including

PSoC Creator, PSoC Programmer, and PDL. However, it does not include the Windows

Installer or Microsoft .NET framework packages. If these packages are not on your computer,

the installer will direct you to download and install them from the Internet.

b. CY8CKIT-059 Kit Only: This executable file installs only the kit contents, which include kit

code examples, hardware files, and user documents. This package can be used if all the

software prerequisites (listed in step 5) are installed on your PC.

c. CY8CKIT-059 DVD ISO: This file is a complete package, stored in a DVD-ROM image format,

that you can use to create a DVD or extract using an ISO extraction program such as WinZip

or WinRAR. The file can also be mounted like a virtual CD/DVD using virtual drive programs

such as Virtual CloneDrive and MagicISO. This file includes all the required software, utilities,

drivers, hardware files, and user documents.

2. If you have downloaded the ISO file, mount it in a virtual drive. Extract the ISO contents if you do

not have a virtual drive to mount. Double-click cyautorun.exe in the root directory of the extracted

content or mounted ISO if "Autorun from CD/DVD" is not enabled on the PC. The installation

window will appear automatically. Note: If you are using the "Kit Setup" or "Kit Only" file, then go

to step 4 for installation.
