Technical Data

Connector

M12 connector, 8-pin

M12 connector, 5 pin

M23 connector, 12-pin

10-pin MIL connector

7-pin MIL connector

Cable

Fixed cable with M12 plug. 5-pin

Fixed cable with M12 plug. 8-pin

Standard conformity

Degree of protection

DIN EN 60529, IP65, IP67

Climatic testing

DIN EN 60068-2-78 , no moisture condensation

Emitted interference

EN 61000-6-4:2007/A1:2011

Noise immunity

EN 61000-6-2:2005

Shock resistance

DIN EN 60068-2-27, 300 g, 6 ms

Vibration resistance

DIN EN 60068-2-6, 30 g, 10 ... 2000 Hz

Approvals and certificates

UL approval

cULus Listed, General Purpose, Class 2 Power Source, Type 1 enclosure , if UL

marking is marked on the product.

adapters providing field wiring on request

Maximum permissible ambient temperature

max. 80 °C (max. 176 °F)

Ambient conditions

Operating temperature

-40 ... 85 °C (-40 ... 185 °F) , fixed cable

-5 ... 85 °C (23 ... 185 °F) , movable cable

Storage temperature

-40 ... 85 °C (-40 ... 185 °F)

Mechanical specifications

Material

Housing

3.2315 aluminum (AlMgSi1, saltwater-proof)

Flange

3.2315 aluminum (AlMgSi1, saltwater-proof)

Shaft

Recessed hollow shaft Stainless steel

Mass

< 300 g without cable

Rotational speed

Moment of inertia

Starting torque

≤ 1.5 Ncm for IP65 , ≤ 2.5 Ncm for IP67

Shaft load

Angle offset

max. 1 °

Axial offset

max. 1 mm

Accessories

9416

Female connector

9416L

Female connector

V19-G-10M-PVC-TP

Female cordset, M12, 8-pin, shielded, PVC cable

V19-G-2M-PVC-TP

Female cordset, M12, 8-pin, shielded, PVC cable

V19-G-5M-PVC-TP

Female cordset, M12, 8-pin, shielded, PVC cable

V19-G-BK2M-PUR-U

Female cordset, M12, 8-pin, PUR-cable

Incremental rotary encoder

ENI58IL-R

4
