Connections

Connector MIL7

Connector MIL10

∼ 27.5

∼ 40.5

51.5

13

38

ø 48

X H7

ø 3/8“

ø 9.525

ø 1/2“

ø 12.7

ø 1/4“

ø 6.35

ø 15

ø 15

ø 14

ø 14

ø 12

ø 12

ø 10

ø 10

ø 8

ø 8

ø 6

ø 6

X [mm]

M3 (6x)

Recessed hollow shaft with MIL connector (radial)

Recessed

hollow shaft

Max. insertion depth = 23

Min. insertion depth = 15

Connections

Connector MIL7

Connector MIL10

18

18

Incremental rotary encoder

ENI58IL-R

2
