PLL702-06

Clock Generator for Printer Applications

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991

www.phaselink.com

Rev 10/26/05 Page 5

Electrical Specifications

1. Absolute Maximum Ratings

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage

4.6

V

Input Voltage, dc

-0.5

V

Output Voltage, dc

-0.5

V

Storage Temperature

-65

150

°C

Ambient Operating Temperature*

0

70

°C

Junction Temperature

125

°C

Lead Temperature (soldering, 10s)

260

°C

ESD Protection, Human Body Model

2

kV

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the device and affect product

reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other conditions above the operational limits noted in this

specification is not implied.

2. AC Specifications

PARAMETERS

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Crystal Input Frequency

14.31818

MHz

SST modulation sweep rate

28

kHz

Output Rise Time

0.8V to 2.0V with no load

1.5

ns

Output Fall Time

2.0V to 0.8V with no load

1.5

ns

Duty Cycle

At VDD/2

45

50

55

%

Max. Absolute Period Jitter

Long term, No SST

180

ps

Max. Jitter, cycle to cycle

Long term + Short term

150

ps
