PLL701-17

Low EMI Spread Spectrum Multiplier Clock

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991

www.phaselink.com

Rev 01/17/06 Page 3

2. DC/AC Specifications

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Supply Voltage

2.97

3.63

V

Supply Current

15pF Load, FOUT=16MHz

9

mA

5pF Load, FOUT=200MHz

25

mA

Input High Voltage

V

Input Low Voltage

V

Input High Current

100

µA

Input Low Current

100

µA

Output High Voltage

2.4

Output Low Voltage

0.4

S3=0 or S3-S2=1-1

16

40

MHz

S3-S2-S1=1-0-1

24

50

MHz

Input Frequency

S3-S2-S1=1-0-0

24

60

MHz

1

ms

Input Capacitance

3

pF

Pull-up Resistor

PIN 2, 3

30

k

Ω

Pull-down Resistor

PIN 4, 7

30

k

Ω

Short Circuit Current

50

mA

No Load, FOUT=16MHz

7

mA

3.3V Dynamic Supply Current

No Load, FOUT=200MHz

21

mA

3. TIMING CHARACTERISTICS

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

10%~90%VDD, 15pF Load, FOUT≤100MHz

2

3

ns

10%~90%VDD, 10pF Load, FOUT≤150MHz

1.5

2

ns

Rise Time

10%~90%VDD, 5pF Load, FOUT≤200MHz

1

1.5

ns

90%~10%VDD, 15pF Load, FOUT≤100MHz

2

3

ns

90%~10%VDD, 10pF Load, FOUT≤150MHz

1.5

2

ns

Fall Time

90%~10%VDD, 5pF Load, FOUT≤200MHz

1

1.5

ns

Output Duty Cycle

Measured at 50%VDD

45

50

55

%

Cycle to Cycle Jitter

Over output frequency range @ 3.3V

100

ps peak
