PLL702-05

Low EMI Peripheral Clock Generator for Notebook

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991

www.phaselink.com

Rev 08/12/04 Page 4

Electrical Specifications

1. Absolute Maximum Ratings

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage

4.6

V

Input Voltage, dc

-0.5

V

Output Voltage, dc

-0.5

V

Storage Temperature

-65

150

°C

Ambient Operating Temperature*

-40

85

°C

Junction Temperature

125

°C

Lead Temperature (soldering, 10s)

260

°C

ESD Protection, Human Body Model

2

kV

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the device and affect product

reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other conditions above the operational limits noted in this

specification is not implied.

* Note: Operating Temperature is guaranteed by design for all parts (COMMERCIAL and INDUSTRIAL), but tested for COMMERCIAL grade only.

2. AC Specifications

PARAMETERS

CONDITIONS

MIN.

TYP.

MAX.

UNITS

14.31818

MHz

Input Frequency (to be set via XTAL_SEL)

+/- 20ppm accuracy

24.576

MHz

Output Rise Time

10% to 90% with no load

0.5

ns

Output Fall Time

90% to 10% with no load

0.5

ns

Duty Cycle

At VDD/2

40

50

60

%

Max. Absolute Period Jitter

Long term, No SST

500

ps

Max. Jitter, cycle to cycle

Long term + Short term

400

ps

Clock Settle Time

22

25

ms

Crystal Load Capacitance

Excluding PCB parasitics

21

pF

Crystal ESR

30

Ω
