background image
HMC1126ACEZ
Data Sheet
Rev. 0 | Page 4 of 21
26 GHz TO 40 GHz FREQUENCY RANGE
TA = 25°C, VDD = 5 V, VGG2 = 1 V, and IDQ = 85 mA, unless otherwise stated. Adjust VGG1 between −2 V and 0 V to achieve IDQ = 85 mA typical.
Table 3.
Parameter
Min
Typ
Max
Unit
Test Conditions/Comments
FREQUENCY RANGE
26
40
GHz
GAIN
10.5
12.5
dB
Gain Variation over Temperature
0.007
dB/°C
RETURN LOSS
Input
13.5
dB
Output
16
dB
OUTPUT
OP1dB
16
dBm
PSAT
20
dBm
OIP3
27
dBm
POUT per tone = 0 dBm with 1 MHz tone spacing
NOISE FIGURE
4.5
dB
SUPPLY
IDQ
85
mA
Adjust VGG1 to achieve IDQ = 85 mA typical
VDD
3.3
5
V
40 GHz TO 52 GHz FREQUENCY RANGE
TA = 25°C, VDD = 5 V, VGG2 = 1 V, and IDQ = 85 mA, unless otherwise stated. Adjust VGG1 between −2 V and 0 V to achieve IDQ = 85 mA typical.
Table 4.
Parameter
Min
Typ
Max
Unit
Test Conditions/Comments
FREQUENCY RANGE
40
52
GHz
GAIN
12
dB
Gain Variation over Temperature
0.01
dB/°C
RETURN LOSS
Input
7.5
dB
Output
15
dB
OUTPUT
OP1dB
12.5
dBm
PSAT
17.5
dBm
OIP3
23.5
dBm
POUT per tone = 0 dBm with 1 MHz tone spacing
NOISE FIGURE
6
dB
SUPPLY
IDQ
85
mA
Adjust VGG1 to achieve IDQ = 85 mA typical
VDD
3.3
5
V
