OUTLINE DIMENSIONS

SEATING

PLANE

PIN 1

CORNER

TOP VIEW

BOTTOM VIEW

5.10

5.00 SQ

4.90

SIDE VIEW

PIN 1 CORNER

INDICATOR

0.29

0.25

0.21

1.70

1.60

1.50

FOR PROPER CONNECTION OF

THE EXPOSED PADS, REFER TO

THE PIN CONFIGURATION AND

FUNCTION DESCRIPTIONS

SECTION OF THIS DATA SHEET.

0.35

0.30

0.25

2.90 BSC

SQ

1

6

7

12

13

18

19

24

0.50

0.45

0.40

0.10

BSC

1.35 REF

0.18

Ø 0.15

0.12

(Vent Hole)

0.65

BSC

3.25

REF

Figure 68. 24-Terminal Chip Array Small Outline No Lead Cavity [LGA_CAV]

5.00 mm × 5.00 mm Body and 1.60 mm Package Height

(CE-24-2)

Dimensions shown in millimeters

ORDERING GUIDE

Temperature Range

MSL

Package Description

Package Option

HMC1126ACEZ

−40°C to +85°C

MSL3

24-Terminal Chip Array Small Outline No Lead Cavity [LGA_CAV]

CE-24-2

HMC1126ACEZ-R7

−40°C to +85°C

MSL3

24-Terminal Chip Array Small Outline No Lead Cavity [LGA_CAV]

CE-24-2

HMC1126-EVALZ

Evaluation Board

1

Z = RoHS Compliant Part.

2

When ordering the evaluation board only, reference the model number, HMC1126-EVALZ.

3

See the Absolute Maximum Ratings section for additional information.
