1. Overall Introduction

Raytac

’s MDBT50Q & MDBT50Q-P is a BT 5.2 stack (Bluetooth low energy or BLE) module

designed based on Nordic nRF52840 SoC solution, which incorporates: GPIO, SPI, UART,

I2C, I2S, PMD, PWM, ADC, NFC and USB interfaces for connecting peripherals and sensors.

Features:

Embedded 2.4GHz transceiver supports Bluetooth 5.2 (

), IEEE 802.15.4

(

& Zigbee) & 2.4Ghz RF & ANT+

upon customer’s preference.

Compact size with (L) 15.5 x (W) 10.5 x (H) 2.05 or 2 mm.

Low power requirements, ultra-low peak, average and idle mode power consumption.

Be compatible with a large installed base of mobile phones, tablets and computers.

Fully coverage of BLE software stack.

BLE & RF transmission switching helps products fit all operation system and most

hardware.

1.1.

Application

‧IoT Networks

‧Smart home (such as door locks, lighting) sensors and controllers

‧Smart city sensor networks

‧Industrial IoT sensors and controllers

‧Connected white goods

‧Personal Area Networks

‧Health / fitness sensor and monitor device

‧Medical device

‧Interactive entertainment devices

‧Advanced remote controls

‧Gaming controller

‧Advanced wearables

‧Connected watches

‧Advanced personal fitness devices

‧Wearables with wireless secure payment

‧Connected Health

‧Virtual/Augmented Reality applications

‧High performance HID Controllers

‧Mesh Network
