1.2.

Features

‧Bluetooth 5, IEEE 802.15.4, 2.4 GHz transceiver

‧-95dBm sensitivity in 1Mbps Bluetooth low energy (BLE) mode

‧-103dBm sensitivity in 125Kbps BLE mode (long range)

‧+8 dBm TX power (down to -20 dBm in 4 dB steps)

‧On-air compatible with nRF52, nRF51, nRF24L and nRF24AP Series

‧Programmable output power from +8dBm to -20dB

‧RSSI (1dB resolution)

‧Supported data rates:

‧Bluetooth 5: 2 Mbps, 1 Mbps, 500 kbps, 125 kbps

‧IEEE 802.15.4-2006: 250 kbps

‧Proprietary 2.4 GHz: 2 Mbps, 1 Mbps

‧ARM Cortex

–M4 32-bit processor with FPU, 64 MHz

‧Memory: 1MB flash / 256KB RAM

‧HW accelerated security

‧ARM TrustZone Cryptocell 310 security subsystem

‧128 bit AES / ECB / CCM / AAR co-processor (on-the-fly packet encryption)

‧Advanced on-chip interfaces

‧USB 2.0 full speed (12Mbps) controller

‧QSPI 32MHz interface

‧High speed 32MHz SPI

‧Type 2 near field communication (NFC-A) tag with wake-on field

‧Programmable peripheral interconnect (PPI)

‧48 general purpose I/O pins

‧EasyDMA automated data transfer between memory and peripherals.

‧12 bit, 200ksps ADC

– 8 configurable channels with programmable gain

‧4 x 4 channel pulse width modulator (PWM) units with EasyDMA

‧Audio peripherals : I2S, digital microphone interface (PDM)

‧5 X 32-bit timers with counter mode

‧Up to 4 x SPI masters / 3 x SPI slaves with EasyDMA

‧Up to 2 x I2C compatible 2-wire masters / slaves

‧2 x UART(CTS/RTS) with EasyDMA

‧Quadrature decoder (QDEC)

‧3 x 24-bit real-time counters (RTC)
