Grommets for Cable Entry System Frames for Terminated Cables

• Place grommets around cables and insert into Cable Entry System Frames for

Terminated Cables (see pages 2-3)

• Three sizes allow cables from 0.08" up to 1.18" diameter to route into control panels

• Cable grommets available for ASI cables

• Use cable tie part number PLT2S-C0 to secure cable within grommet

• Manufactured from TPE materials

• Flammability: UL94V-0

• Temperature rating: -22 °F – 212 °F (-30 °C – 100 °C)

Part

Number

Compatibility for

Frame Opening

Number of Opening

for Cables

Cable Diameter

Std. Pkg.

Qty.

Std. Ctn.

Qty.

In

mm

CEG-02X1

Small

1

0.08 - 0.12

2.0 - 3.0

12

1200

CEG-03X1

0.12 - 0.16

3.0 - 4.1

CEG-04X1

0.16 - 0.20

4.1 - 5.1

CEG-05X1

0.20 - 0.24

5.1 - 6.1

CEG-06X1

0.24 - 0.28

6.1 - 7.1

CEG-07X1

0.28 - 0.31

7.1 - 7.9

CEG-08X1

0.31 - 0.35

7.9 - 8.9

CEG-09X1

0.35 - 0.39

8.9 - 9.9

CEG-10X1

0.39 - 0.43

9.9 - 10.9

CEG-11X1

0.43 - 0.47

10.9 - 11.9

CEG-12X1

Medium

0.47 - 0.51

11.9 - 13.0

4

300

CEG-13X1

0.51 - 0.55

13.0 - 14.0

CEG-14X1

0.55 - 0.59

14.0 - 15.0

CEG-15X1

0.59 - 0.63

15.0 - 16.0

CEG-16X1

0.63 - 0.67

16.0 - 17.0

CEG-17X1

0.67 - 0.71

17.0 - 18.0

CEG-18X1

0.71 - 0.75

18.0 - 19.1

CEG-19X1

0.75 - 0.79

19.1 - 20.1

CEG-20X1

0.79 - 0.83

20.1 - 21.1

CEG-21X1

0.83 - 0.87

21.1 - 22.1

CEG-22X1

Large

0.87 - 0.91

22.1 - 23.1

CEG-23X1

0.91 - 0.94

23.1 - 23.9

CEG-24X1

0.94 - 0.98

23.9 - 24.9

CEG-25X1

0.98 - 1.02

24.9 - 25.9

CEG-26X1

1.02 - 1.06

25.9 - 26.9

CEG-27X1

1.06 - 1.10

26.9 - 27.9

CEG-28X1

1.10 - 1.14

27.9 - 29.0

CEG-29X1

1.14 - 1.18

29.0 - 30.0

CEG-02X2

Small

2

0.08 - 0.12

2.0 - 3.0

12

1200

CEG-02X4

4

CEG-03X2

2

0.12 - 0.16

3.0 - 4.1

CEG-03X4

4

CEG-04X2

2

0.16 - 0.20

4.1 - 5.1

CEG-04X4

4

CEG-05X2

Medium

2

0.20 - 0.24

5.1 - 6.1

4

300

CEG-05X4

4

CEG-06X2

2

0.24 - 0.28

6.1 - 7.1

CEG-06X4

4

CEG-07X2

2

0.28 - 0.31

7.1 - 7.9

CEG-07X4

4

CEG-08X2

2

0.31 - 0.35

7.9 - 8.9

CEG-08X4

4

CEG—X1

CEG—X4

Part

Number

Compatibility for

Frame Opening

Description

Std. Pkg.

Qty.

Std. Ctn.

Qty.

CEGASIX2

Medium

Cable bushing to accommodate two ASI bus cables

4

300

CEGAM

Medium

Adapter to allow the use of small grommets in a

medium hole in the frame

4

300

CEGBLS

Small

Blank / Filler Grommet

12

1200

CEGBLM

Medium

Blank / Filler Grommet

4

300

CEGBLL

Large

Blank / Filler Grommet

4

300

CEGASIX2

CEGAM

CEGBLS

CEG—X2

Cable Entry Systems
