Product Bulletin

Cable Entry Systems

Panduit Cable Entry Systems complement our already broad and innovative

control panel and on-machine solution that safely organizes, connects and

protects electrical systems.

The Cable Entry Systems offer a safe, organized method to transition cable

and hoses through enclosures and electrical equipment, providing strain

relief while maintaining IP/NEMA ingress sealing ratings.

Traditional cable glands or cord grips require several time-consuming

installation steps and considerable space on the enclosure; the Panduit

offering simplifies the installation and can manage numerous cables in a

very dense space. These design benefits provide up to 80% installation

time savings dramatically increasing productivity and freeing up installers

for other activities. The high-density hole configurations provide up to 80%

space savings which is critical for machine applications that require several

cables with limited space on the equipment. The extra hole locations in the

same dense design allow for future cabling moves, adds, and changes.

While cable glands or cord grips typically only handle unterminated cables,

the Panduit system handles both unterminated and terminated cables for

increased installation productivity.

For more information about the Cable Entry Systems

visit www.panduit.com/cable-entry-systems.

FEATURE

BENEFIT

Round and rectangular solutions

available

Up to 80% labor savings and 80% space savings when multiple cables are

required to pass into same enclosure. One hole / punch can accommodate

up to 12 terminated cables and up to 140 unterminated cables.

Accommodates terminated and

un-terminated cables

Prevents re-termination of cables in order to pass through openings

Selection of IP ratings to accommodate

customer requirements

Meets multiple IP/NEMA ingress sealing ratings to accommodate a variety

of applications that lets the user determine the most suitable solution for

their requirements.

Compatible with standard punch tools

The circular and rectangular designs are compatible with industry standard

electrical cutout punches to ease installation.

Imperial dimensions physically

molded into components

Provides easy reference for customers who standardize on imperial

dimensions

Strain relief

Grommets and sealing membranes prevent cables from over-bending

at cable entry points
