Cable Entry System Plates for Un-Terminated Cables -

Rectangular - Metal

• Aluminum and stainless steel plates are best for high density cabling

and the most demanding environments

• Stainless steel version is suitable for application in the food and chemical areas

• Engineered cable entry system offering a high degree of strain relief

• IP65 (NEMA Type 1 and 12)

• Stainless steel products include integrated fasteners. Aluminum products

require four (4) user supplied 10-32 screws and nuts for mounting.

• Seals are manufactured from NBR / EDPM materials

• Temperature rating: -22 °F - 194 °F (-30 °C - 90 °C)

Part Number

Material

Total

Number of

Openings

Number of

Openings

Size of Openings

Overall Dimensions

Std.

Pkg.

Qty.

Std.

Ctn.

Qty.

Length

Width

Installed Height

In

mm

In

mm

In

mm

In

mm

CESU2-F25-AL+

Aluminum

25

9

0.12 - 0.20

3.0 - 5.1

5.67

144.0

3.54

89.9

0.22

5.6

1

5

16

0.16 - 0.31

4.1 - 7.9

CESU2-F8-AL+

8

8

0.63 - 1.1

16.0 - 27.9

15.51

393.7

CESU2-F47-AL

47

14

0.14 - 0.26

3.6 - 6.6

8.7

221.0

28

0.18 - 0.33

4.6 - 8.4

4

0.28 - 0.43

7.1 - 10.9

1

0.43 - 0.63

10.9 - 16.0

CESU2-F47-SS*

Stainless

Steel

47

14

0.14 - 0.26

3.6 - 6.6

0.20

5.0

28

0.18 - 0.33

4.6 - 8.4

4

0.28 - 0.43

7.1 - 10.9

1

0.43 - 0.63

10.9 - 16.0

CESU2-H140-SS*+

140

16

0.14 - 0.24

3.6 - 6.1

21.02

533.9

5.87

149.1

0.22

5.6

64

0.18 - 0.33

4.6 - 8.4

36

0.24 - 0.39

6.1 - 9.9

4

0.31 - 0.47

7.9 - 11.9

8

0.35 - 0.55

8.9 - 14.0

8

0.55 - 0.71

14.0 - 18.0

4

0.71 - 0.98

18.0 - 24.9

*Integrated threaded bolts mean that no screws are visible from the outside

+UL Recognized only (UR)

For cutout dimensions, scan the QR code

or visit www.panduit.com/cable-entry-system-drawings
