ADCMP603
Rev. 0 | Page 9 of 16
8
7
6
5
4
2
3
OVERDRIVE (mV)
0
10 20 30 40 50 60 70 80 90 100 110 120
140
130
500mV/DIV
M2.00ns
Figure 10. Propagation Delay vs. Input Overdrive
Figure 12. 50 MHz Output Voltage Waveform at VCCO = 2.5 V
–0.6
0
0.6
1.2
1.8
2.4
3.0
4.0
3.8
3.6
3.4
3.2
3.0
COMMON-MODE VOLTAGE (V)
PROP DELAY RISE ns
PROP DELAY FALL ns
VCC = 2.5V
1.00V/DIV
M2.00ns
Figure 13. 50 MHz Output Voltage Waveform at V
Figure 11. Propagation Delay vs. Input Common Mode
CCO
= 5.5 V
