CLM2D-RCC/ACC: PLCC4 RED & AMBER SMD LEDs

© 2021-2024 Cree LED. The information in this document is subject to change without notice. Cree®, the Cree logo and the Cree LED logo are registered

trademarks of Cree LED.

CLD-CT1409

REV 6

3

INTENSITY BIN LIMIT

Red (20 mA)

Amber (20 mA)

Bin Code

Min.(mcd)

Max.(mcd)

Bin Code

Min.(mcd)

Max.(mcd)

Xa

1800

2240

Xa

1800

2240

Xb

2240

2800

Xb

2240

2800

Ya

2800

3550

Ya

2800

3550

Yb

3550

4500

Yb

3550

4500

Z0

4500

5600

Z0

4500

5600

*

Tolerance of measurement of luminous intensity is ±10%

COLOR BIN LIMIT

Red (20 mA)

Amber (20 mA)

Bin Code

Min.(nm)

Max.(nm)

Bin Code

Min.(nm)

Max.(nm)

RB

619

624

A2

584

587

A3

587

590

A4

590

593

A5

593

596

*

Tolerance of measurement of dominant wavelength is ±1 nm.
