CLM2D-RCC/ACC: PLCC4 RED & AMBER SMD LEDs

© 2021-2024 Cree LED. The information in this document is subject to change without notice. Cree®, the Cree logo and the Cree LED logo are registered

trademarks of Cree LED.

CLD-CT1409

REV 6

2

ABSOLUTE MAXIMUM RATINGS (T

A = 25°C)

Items

Symbol

Absolute Maximum Rating

Unit

Red

Amber

Forward Current

I

F

70

mA

Peak Forward Current Note1

I

FP

200

mA

Reverse Voltage

V

R

5

V

Power Dissipation

P

D

182

mW

Operation Temperature

T

opr

-40 ~ +100

°C

Storage Temperature

T

stg

-40 ~ +100

°C

Junction Temperature

T

J

110

°C

Junction/Ambient

R

THJA

250

°C/W

Junction/Solder Point

R

THJS

100

°C/W

Electrostatic Discharge

Classification(MIL-STD-883E)

ESD

Class 2

Note:

1.

Pulse width ≤0.1 msec, duty ≤1/10.

TYPICAL ELECTRICAL & OPTICAL CHARACTERISTICS (T

A = 25°C)

Characteristics

Color

Symbol

Condition

Unit

Minimum

Typical

Maximum

Forward Voltage

Red

V

F

I

F = 20 mA

V

2.0

2.6

Amber

V

F

I

F = 20 mA

V

2.1

2.6

Reverse Current

Red/Amber

I

R

V

R = 5 V

μA

10

Dominant Wavelength

Red

λ

D

I

F = 20 mA

nm

619

621

624

Amber

λ

D

I

F = 20 mA

nm

584

590

596

Luminous Intensity

Red

I

V

I

F = 20 mA

mcd

1800

3500

Amber

I

V

I

F = 20 mA

mcd

1800

3500

50% Power Angle

Red/Amber

2θ½

I

F = 20 mA

deg

30

*

Continuous reverse voltage can cause LED damage.
