Ordering Information

Product Sales Code

Description

Package

ZSC31150KIT

Evaluation Kit V1.0

Modular evaluation and development boards for

ZSC31150

KIT boards, IC samples, USB cable,

DVD with software and documentation

ZSC31150 Mass

Calibration System V1.1

Modular Mass Calibration System (MSC) for

ZSC31150

MCS boards, cable, connectors,

DVD with software and documentation

9

Additional Documents

Document

File Name

ZSC31150 Feature Sheet

ZSC31150_FeatureSheet_Rev_*.PDF

ZSC31150 Functional Description

ZSC31150_FunctionalDescription_Rev_*.PDF

ZSC31150 High Voltage Protection Description

ZSC31150_HV_PROT_Rev_*.PDF

ZSC31150 Dice Package

ZSC31150_DicePackagePin_Rev_*.PDF

ZSC31150 Bandwidth Calculation Sheet

ZSC31150_Bandwidth_Calculation_Rev*.xls

ZMDI Temperature Profile Calculation Sheet

ZMDI_Temperature_Profile_Rev_*.xls

ZSC31150 Application Kit Description

ZSC31150_APPLKIT_Rev_*.pdf

ZSC31150 Application Notes

ZSC31150_AN*.pdf
