ZSC31150

Fast Automotive Sensor Signal Conditioner

Data Sheet

August 31, 2010

© 2010 Zentrum Mikroelektronik Dresden AG — Rev. 1.07

All rights reserved. The material contained herein may not be reproduced, adapted, merged, translated, stored, or used without

the prior written consent of the copyright owner. The information furnished in this publication is subject to changes without

notice.

8 of 24

No.

Parameter

Symbol

Conditions

Min

Typ

Max

Unit

1.3.5. Sensor Connection Check

1.3.5.1

Sensor connection loss

RSCC_min

detection threshold

100

k



1.3.5.2

Sensor input short

RSSC_short

short detection

guaranteed

0

50



1.3.5.3

Sensor input no short

RSSC_pass

short is never detected

1000



1.3.6. DAC & Analog Output (Pin AOUT)

1.3.6.1

D/A Resolution

rDAC

analog output, 10-90%

12

Bit

1.3.6.2

Output current sink and

source for VDDE=5V

ISRC/SINK_OUT

VOUT: 5-95%,

RLOAD>=2kΩ

VOUT: 10-90%,

RLOAD>=1kΩ

2.5

5

mA

1.3.6.3

Short circuit current

IOUT_max

to VSSE/VDDE

1

-25

25

mA

1.3.6.4

Addressable output signal

range

VSR_OUT95

VSR_OUT90

@ RLOAD>=2k

@ RLOAD>=1k

0.05

0.1

0.95

0.9

VDDE

1.3.6.5

Output slew rate

2

SROUT

CLOAD < 50nF

0.1

V/µs

1.3.6.6

Output resistance in

diagnostic mode

ROUT_DIA

Diagnostic Range:

<4|96>%, RLOAD>=2k

<8|92>%, RLOAD>=1k

82



1.3.6.7

Load capacitance

2

CLOAD

C3 + CL (refer chapter 3)

150

nF

1.3.6.8

DNL

DNLOUT

-1.5

1.5

LSB

1.3.6.9

INL TQA

2

INLOUT

best fit, rDAC =12Bit

-5

5

LSB

1.3.6.10

INL TQE

INLOUT

best fit, rDAC =12Bit

-8

8

LSB

1.3.6.11 Output Leakage current @

150grd

ILEAK_OUT

in case of power or

ground loss

-25

25

µA

1.3.7. System Response

1.3.7.1

Startup time

3

tSTA

to 1st output, fCLK=3MHz,

no ROM check, ADC:

14bit & 2nd order

5

ms

1.3.7.2

Response time

(100% jump)

2

tRESP

fCLK=4MHz, 13Bit, 2nd

order, refer Table 2.3

256

512

µs

1.3.7.3

Bandwidth

2

comparable to analog

SSCs

5

kHz

1.3.7.4

Analog Output Noise

Peak-to-Peak

2

VNOISE,PP

shorted inputs, gain=

bandwidth

 10kHz

10

mV

1.3.7.5

Analog Output Noise

RMS

2

VNOISE,RMS

shorted inputs, gain=

bandwidth

 10kHz

3

mV

1

minimum output voltage to VDDE or maximum output voltage to VSSE

2

No measurement in mass production, parameter is guaranteed by design and/or quality observation.

3

Depends on resolution and configuration - start routine begins approximately 0.8ms after power on
