CC1010

SWRS047A

Page 82 of 146

ADCON 2(0x96) - ADC Control Register 2

Bit

Name

R/W

Reset value

Description

ADCIE

R/W

ADC interrupt enable flag. In order for ADCIF to raise

an interrupt, EIE.ADIE must also be set.

ADCIF

R/W

ADC interrupt flag. ADCIF must be cleared by software.

Because the ADC shares an interrupt line with the DES

module, EXIF.ADIF must also be cleared by software

before exiting the interrupt service routine. EXIF.ADIF

should be cleared first so that the 8051 is ready to

receive a new interrupt immediately after ADCIF is

cleared.

5:0

ADCDIV

R/W

0x00

ADC clock divider. Selects ADC clock divider in steps of

16.

000000: Divider is 16

000001: Divider is 32

…

111111: Divider is 1024

ADTRH (0x97) - ADC Threshold Register

Bit

Name

R/W

Reset value

Description

7:0

ADTRH(7:0)

R/W

0x00

ADC comparator threshold value, used to generate ADC

interrupt or chip reset when the threshold is exceeded.
