EPP-R3054 datasheet(43/75 Pages) ABB

43 / 75 page

PROTEC TA PLUS MCB DIS TR IBUTION B OA R D 2 5 0A

Colour

Modules

Order codes

M1363

Grey

M1363

Grey with light

M1363-L

—

British standard modular sockets

—

Modular sockets

Order Codes

Number

of poles

Rated

current

Modules

Order codes

E92

E 91/32

E 91/32s

E 93/32

E94

E 93/32s

—

E 90 fuse switch disconnectors

Order Codes

E 90 series fuse switch disconnectors are

designed for switching circuits under load,

providing protection against short circuits and

overloads. The case is made of self-extinguishing

thermoplastic material resistant to high

temperatures (all materials are UL listed) while

the contact clips are in silver plated copper.

E 90 fuse switch disconnectors can be sealed or

padlocked to ensure operator safety during

maintenance. Versions with blown fuse indicator

allow to check whether the fuse is still working

correctly or not. For easy and quick installation E

90 range is totally compatible with connecting

bars, terminals and caps of S 200 MCBs.

Thanks to cURus approval, they can be installed in

UL certified machines.

—

E 90 fuse switch disconnectors for 10.3 x 38 mm fuses (AC-22B)

E94

Fuses not included
