6mm Process Sealed SMT Tactiles

Series CB3

TYPICAL SWITCH ORDERING EXAMPLE

CB3

SPST

OFF-(ON) Circuit

Flat Button

Gull Wing Terminals

for Upright Mount

POLE & CIRCUIT

OFF

(ON)

( ) = Momentary

F

DESCRIPTION FOR TYPICAL ORDERING EXAMPLE

CB315FP

15

ACTUATOR

F

Flat Button

TERMINALS

P

Gull Wing for

Upright Mount

PACKAGING

R

Tape-Reel

1,000 Pieces/Reel

No

Code

Partitioned Tray

P

POLE & CIRCUIT

Actuator Position

( ) = Momentary

Switch Throw & Schematic

Pole

Model

Normal

Down

Note: Terminal numbers are

not actually on switch.

SP

CB315

OFF

(ON)

SPST

1

2

3

4

TYPICAL SWITCH DIMENSIONS

Single Pole • Single Throw

CB315FP

(3.1)

.122

(0.3) Typ

.012

(0.65)

.026

(6.2)

.244

(6.2)

.244

(3.0) Dia

.118

(4.35) Dia

.171

(9.0)

.354

(4.0)

.157

1

3

2

4

(0.7) Typ

.028

3

4

2

1

(8.9)

.350

(4.0)

.157

(1.4) Typ

.056

(1.7) Typ

.067
