6mm Process Sealed SMT Tactiles

Series CB3

PACKAGING

R

Tape-Reel (packaged to EIA-481-2 standard)

Switches must be ordered in 1,000-piece increments

when tape-reel packaging is selected.

Partitioned Tray

If less than 1,000 pieces are ordered, the switches are

packaged in a partitioned tray. No code is required.

No

Code

Tape-Reel Dimensions & Specifications

Each tape-reel of 1,050 pockets contains 1,000 switches

Minimum Leader Length: 16.54” (420mm)

Minimum Trailer Length: 7.09” (180mm)

(9.4)

.370

(3.8)

.150

(3.4)

.134

(0.4)

.016

(16.0)

.630

(1.75)

.069

(7.5)

.295

(4.0) Typ

.157

(6.7) Typ

.264

(12.0) Typ

.472

(2.0) Typ

.079

(1.5) Dia Typ

.059

Direction of Feed

(78.49) Dia

3.090

(2.0)

.079

(16.4)

.646

(13.0) Dia

.512

(2.0) Typ

.079

(21.0) Dia

.827

Overall Dia (330.0)

13.0

KEYBOARD MATRIX

Blue = PCB Trace, Black = Switch Circuit

These single pole, single throw switches can be used in a key-

board matrix and, using strapped terminals, achieve a com-

mon bus electrical configuration on a single-sided PC board.

These single pole, single throw switches can be arranged

on a single-sided PC board matrix with strapped termi-

nals to achieve an X-Y type electrical interconnection.

Common Bus Matrix

X-Y Matrix

Blue = PCB Trace, Black = Switch Circuit

1

2

3

6

5

4

7

8

9

B

0

A

1

2

6

7

3

4

5

1

2

3

4

5

6

7

8

9

0

A

B

1 2 3 4 5 6 7

= ON

PC Terminations

1

2

3

4

5

6

7

8

9

0

A

B

1 2 3 4 5 6 7 8 9 10 11 12 13

= ON

P C Te r m i n a t i o n s

1

2

3

6

5

4

7

8

9

B

0

A

9

13

10

6

11

8

12

7

2

1

3

4

5
