CM10 Series

http://www.ddknet.co.jp

◎ Specifications and/or dimensions in this catalog are subject to change without notice.

  Your checking the latest specifications with our drawings would be highly appreciated.

○ Straight Cable Receptacle

○Receptacle

・Pin contact style only

・Soldering termination only

・Conductor Size : 20 AWG Max.

・Individually waterproof

・Pin contact style only

・Soldering termination only

・Conductor Size : 20 AWG Max.

・Individually waterproof

Contact No.10 grounded to shell with ground lug

□17.26

□23.4

4-φ3.2

1.7

8.4

(7.9)

5.2

(13.6)

DDK

2

1

1

2

Main key positon mark

10 Pins

2 Pins

P/N

CM10-R10P(D3)-01

P/N

CM10-R2P(D3)-01

□17.26

□23.4

4-φ3.2

1.7

8.4

(7.9)

5.2

(13.6)

DDK

7

10

8

4

1

3

3

1

4

8

10

7

Main key positon mark

3 min.

1

0

-0.1

4-M3

Mounting Dimensions

10 Pins

2 Pins

・Pin contact style only

・Soldering termination only

・Conductor Size : 20 AWG Max.

・Insulation Dia. : φ 1.87 Max.

P/N

Cable Outside Dia.

CM10-CR10P-S

φ 4.0 ∼φ 6.0

CM10-CR10P-M

φ 6.0 ∼φ 9.0

CM10-CR10P-L

φ 9.0 ∼φ 11.6

P/N

Cable Outside Dia.

CM10-CR2P-S

φ 4.0 ∼φ 6.0

CM10-CR2P-M

φ 6.0 ∼φ 9.0

CM10-CR2P-L

φ 9.0 ∼φ 11.6

３１

４

１０

７

８

（51.3）

（51.3）

・Pin contact style only

・Soldering termination only

・Conductor Size : 20 AWG Max.

・Contact No.10 grounded to shell with ground lug

Note: The applicable cable outside diameter is in the case of cabtyre cable. Please contact the nearest sales office when you use

a different cable.
