9 / 29 page  • All specifications are subject to change without notice. (8/28) 002-01 / 20130301 / e9412_mmz SHAPES AND DIMENSIONS/RECOMMENDED PC BOARD PATTERN SPECIFICATIONS PACKAGING STYLE AND QUANTITIES RECOMMENDED SOLDERING CONDITION REFLOW SOLDERING ELECTRICAL CHARCTERISTICS Test equipment: E4991A or equivalent Test tool : 16192A or equivalent Test temperature: 25±10°C TYPICAL ELECTRICAL CHARACTERISTICS Z FREQUENCY CHARACTERISTICS(DIFFERS ACCORDING TO SERIES) MMZ1005B SERIES MMZ1005S SERIES MMZ1005Y SERIES MMZ1005D SERIES MMZ1005F SERIES Operating temperature range –55 to +125°C Storage temperature range –55 to +125°C(After mount) Packaging style Quantity Taping 10000 pieces/reel 0.1min. 1 ±0.05 0.4 0.5 0.5 Weight: 1mg Dimensions in mm Natural cooling 10s max. Preheating 60 to 120s Soldering 30 to 60s 230˚C 250 to 260˚C 180˚C 150˚C Time(s) Part No. Impedance ( )[100MHz] DC resistance ( )max. Rated current (mA)max. MMZ1005B800C 80±25% 0.19 450 MMZ1005B121C 120±25% 0.25 400 MMZ1005B601C 600±25% 0.85 200 MMZ1005S800C 80±25% 0.12 500 MMZ1005S121C 120±25% 0.22 500 MMZ1005S241C 240±25% 0.28 400 MMZ1005S601C 600±25% 0.52 300 MMZ1005S102C 1000±25% 0.75 200 MMZ1005Y400C 40±25% 0.10 550 MMZ1005Y800C 80±25% 0.17 450 MMZ1005Y121C 120±25% 0.18 400 MMZ1005Y241C 240±25% 0.26 300 MMZ1005Y301C 300±25% 0.38 250 MMZ1005Y471C 470±25% 0.47 250 MMZ1005Y601C 600±25% 0.54 250 MMZ1005Y102C 1000±25% 0.70 200 MMZ1005Y152C 1500±25% 1.00 100 MMZ1005D100C 10±5 0.10 500 MMZ1005D220C 22±25% 0.17 400 MMZ1005D330C 33±25% 0.24 400 MMZ1005D680C 68±25% 0.38 400 MMZ1005D121C 120±25% 0.60 350 MMZ1005D241C 240±25% 0.90 200 MMZ1005F330C 33±25% 0.50 200 MMZ1005F470C 47±25% 0.60 100 MMZ1005F560C 56±25% 0.70 100 10000 1000 100 10 1 Frequency(MHz) 0 200 400 600 800 1000 1200 1400 1600 1800 MMZ1005Y152C MMZ1005Y102C MMZ1005Y601C MMZ1005Y471C MMZ1005Y301C MMZ1005Y241C MMZ1005Y121C MMZ1005Y800C MMZ1005Y400C 10000 1000 100 10 1 Frequency(MHz) 0 100 200 300 400 500 600 700 800 MMZ1005B601C MMZ1005B121C MMZ1005B800C 10000 1000 100 10 1 Frequency(MHz) 0 200 400 600 800 1000 1200 1400 MMZ1005S102C MMZ1005S601C MMZ1005S241C MMZ1005S121C MMZ1005S800C 10000 1000 100 10 1 Frequency(MHz) 0 500 1000 1500 2000 2500 3000 MMZ1005D241C MMZ1005D121C MMZ1005D680C MMZ1005D330C MMZ1005D220C MMZ1005D100C 10000 1000 100 10 1 Frequency(MHz) 0 200 400 600 800 1000 1200 MMZ1005F560C MMZ1005F470C MMZ1005F330C |
|
|
