E3G

10

Dimensions

Sensors

Retro-reflective Models

(Unit: mm)

Tolerance class IT16 applies to dimensions in this datasheet unless otherwise specified.

47.8

45

Two, 4.5-dia.

mounting

holes

18.8

24.4

R11

1.1

12

R7

Receiver

Emitter

21

12

67.8

68.5

22

14

25

29

43

6-dia. vinyl-insulated round cable with 3 conductors

Insulator diameter: 1.3 mm),

Standard length: 2 m

Two, M4

25

Operation selector

Operation indicator (orange)

Stability indicator

(green)

M2.6

Sensitivity

adjuster

Pre-wired Model

E3G-R13

Mounting

Holes

Standard Connector Model

E3G-R17

Note: All dimensions other than the

ones specified below are the

same as the corresponding

dimensions of E3G-R13.

8

37

8

43

7

M12 Connector 10.5 dia.

10

OFF-delay adjuster*

M2.6

37

74

Two, M4

ON-delay adjuster*

Two, 4.5-dia.

mounting holes

84.45

14

22

84.95

18.8

12

35.95

74

6

12

29

2.1

16

37

Hexagonal nut

(Diagonal: 22)

Applicable cable:

6 to 8 dia.

68

44

Operation

selector

Operation indicator (orange)

Stability indicator

(green)

Sensitivity adjuster

R11

R7

Receiver

Emitter

PF1/2 conduit: JIS B 0202

*The ON- or OFF-delay adjuster is not

available with the E3G-MR19.

Terminal Block Models

E3G-MR19

E3G-MR19T

Mounting Holes
