Accessories (Order Separately)

Reflectors

Refer to E39-L/F39-L/E39-S/E39-R for details.

Mounting Brackets

Refer to E39-L/F39-L/E39-S/E39-R for details.

Sensor I/O Connectors

Refer to Introduction to Sensor I/O Connectors for details.

M2.6

61.8

Hexagonal nut

(Diagonal: 22)

Applicable cable:

6 to 8 dia.

90.3

81

44

Cap (provided with the E39-L129)

(PF1/2 conduit: JIS B 0202)

Terminal Protection Cover for Side-pullout Cable

E39-L129

Note: 1. The cover is provided with a rubber bushing and cap

to prevent the cable from being pulled out vertically.

2. Refer to page 9 for the mounting method of the

product.

19

22

81.5

29

M2.6

Terminal Protection Cover for Side-pullout Cable

(Example: E3G-MR19)
