Table 6. AC ELECTRICAL CHARACTERISTICS

Symbol

Parameter

Min

Typ

Max

Unit

CLKIN

Input Clock Frequency

120

240

Hz

CLKOUT

Output Clock Frequency

60

120

Hz

Output Rise / Fall time (Measured from 20% to 80%) (Notes 1, 2)

10

ms

Input Rise / Fall time (Measured from 20% to 80%)

50

ms

49

50

51

%

Input Duty Cycle

49

50

51

%

Set up time for control signals, S[1:4], PD# to input clock rising edge (Note 1)

60

ms

Hold up time for control signals, S[1:4], PD# to input clock rising edge

(Note 1)

60

ms

Output−Output Clock Skew (Note 1)

10

ms

2. All parameters are specified with 15 pF loaded output.

ORDERING INFORMATION

Part Number

Package

P1P3800AG12CRTWG

12 pin (3 mm x 3 mm) WQFN

3000 / Tape & Reel

†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging

Specifications Brochure, BRD8011/D.
