3D7702

MONOLITHIC GATED

DELAY LINE OSCILLATOR

(SERIES 3D7702)

FEATURES

•

All-silicon, low-power CMOS technology

•

TTL/CMOS compatible inputs and outputs

•

Vapor phase, IR and wave solderable

•

Auto-insertable (DIP pkg.)

•

Frequency range: 0.3MHz through 100MHz

•

Frequency tolerance: 0.5% typical

•

Temperature stability:

±1.5% typical (-40C to 85C)

•

Vdd stability:

±0.5% typical (4.75V to 5.25V)

•

14-pin DIP available as drop-in replacements for

hybrid delay line oscillator (DLO32F)

FUNCTIONAL DESCRIPTION

The 3D7702 Delay Line Oscillator product family consists of fixed-

frequency CMOS integrated circuit oscillators. Each package contains a

single oscillator, which is gated and can therefore be synchronized to an

external signal. The device frequency can range from 0.3MHz through

100MHz. The 3D7702 has two outputs that are 180

° out-of-phase when

the oscillator is running, and can be used as a drop-in replacement for

the DLO32F hybrid oscillator. The 3D7702 is TTL- and CMOS-compatible, capable of driving ten 74LS-type

loads. It is offered in a standard 14-pin auto-insertable DIP and a space saving surface mount 8-pin SOIC

package.

PACKAGES

14

13

12

11

10

9

8

1

2

3

4

5

6

7

O1

NC

NC

NC

NC

NC

GND

VDD

NC

NC

NC

O2

NC

EN

3D7702-xx

DIP-14

3D7702K-xx

NC pins removed

1

2

3

4

8

7

6

5

O1

NC

NC

GND

VDD

NC

O2

EN

3D7702Z-xx SOIC-8

PIN DESCRIPTIONS

EN

Oscillator Enable

O1

Oscillator Output 1

O2

Oscillator Output 2

VDD +5 Volts

GND Ground

For mechanical dimensions, click

here.

For package marking details, click

here.
