SmartPro 3kVA Line Interactive UPS, Extended-run

option, Tower, Serial, 120V

MODEL NUMBER: SMART3000NET

Description

Tripp Lite's SMART 3000NET intelligent, line interactive large tower UPS system protects servers, networking

accessories and telecommunications equipment from blackouts, voltage fluctuations and transient surges. Large

internal batteries offer 23 minutes half load runtime and 7 minutes fully loaded. Runtime is expandable with

optional BP24V28-2U (limit 1) and BP24V70-3U (multi-pack compatible) external battery packs. 3000VA/2400 watt power handling capability supports a

variety of networking, telecom and other sensitive electronic applications. Includes 8 protected outlets. Supports remote monitoring of UPS and site power

conditions via built-in RS-232 enabled monitoring port, plus standard UPS monitoring via 2 built in contact closure ports. Includes PowerAlert UPS monitoring

and unattended shutdown software with complete cabling. Built-in audible alarm and front panel LEDs indicate line power, battery power, battery charge level,

load level and voltage regulation status. Network grade AC surge suppression protects equipment from damage and performance problems resulting from

transient surges.

Features

SMART 3000NET line interactive UPS offers battery derived AC output during power outages, voltage regulation during brownouts and overvoltages, plus

network-grade AC surge suppression

3000VA/2400 watt power handling capability supports a variety of networking, telecom and other sensitive electronic devices

Large internal batteries offer runtimes of 23 minutes at half load (1500VA/1200 watts) and 7 minutes at full load (3000VA/2400 watts)

Runtime is further expandable with optional external BP24V28-2U (limit 1) and BP24V70-3U (multi-pack compatible) battery packs

Automatic Voltage Regulation (AVR) circuits maintain 120V nominal output over an input voltage range of 87-140V

Includes 8 fully protected outlets (4 NEMA 5-15R & 4 NEMA 5-15/20R) with 2 single outlet load banks that can be individually powered off and back on

again via software interface

PowerAlert UPS monitoring and unattended shutdown software enables configurable network broadcast messaging, email notification, event logging and

running user defined script commands

Offers simultaneous monitoring of up to 3 directly connected devices through included DB9 contact closure and RS-232 enabled interfaces, or the

monitoring of any number of additional servers over IP with included PowerAlert monitoring software

In addition to the contact closure monitoring of on battery, low battery and power restored messaging, built-in RS-232 interface supports messaging of

UPS and line power status, including AC line voltage, DC battery voltage and remaining battery capacity

Supports activate self-test and UPS output power control for delayed or immediate reboot of connected equipment

Highlights

3kVA / 3000VA line interactive,

extended-run tower UPS

120V nominal output during

brownouts to 87V and

overvoltages to 140V

3 DB9 ports (1 RS232 / 2

contact-closure)

Front panel status LEDs with

load and battery capacity display

2 independently switchable

output load banks

NEMA L5-30P input; 4 NEMA

5-15/20R & 4 NEMA 5-15R

outlets

Package Includes

SMART 3000NET UPS System

PowerAlert Software and three 6

foot network cables

Instruction manual
