Supports activate self-test and UPS output power control for delayed or immediate reboot of connected equipment

Diagnostic LEDs (indicate 17 performance conditions)

Specifications

OUTPUT

Output Volt Amp Capacity (VA)

3000

Output kVA capacity (kVA)

3

Output Watt Capacity (watts)

2400

Output kW capacity

2.4

Output power factor

0.8

Nominal Output Voltage(s)

Supported

120V

Frequency compatibility

60 Hz

Output voltage regulation (line mode)

-13% / +5%

Output voltage regulation (Battery

mode)

+/- 5%

Built-in UPS output receptacles

4 5-15R outlet(s); 4 5-15/20R outlet(s)

Built-in controllable switched load

banks

Two switchable single-outlet 5-15R load banks

Output circuit breaker

15A branch rated (x2) - each breaker protects 4 outlets

Output AC waveform (AC mode)

Sine wave

Output AC waveform (battery mode)

PWM sine wave

INPUT

Rated input current (at maximum

load)

22A

Nominal Input Voltage(s) Supported

120V AC

UPS input connection type

L5-30P

UPS Input cord length (ft.)

8

UPS Input cord length (m)

2.4

Recommended Electrical Service

30A 120V

Input cord length (ft.)

8

Input cord length (m)

2.4

Phase

Single-Phase

BATTERY

Full load runtime (minutes)

7 min. (2400w)
