UPS Shipping dimensions (height x

width x depth / cm)

56.5 x 32.4 x 41.9

Shipping weight (lbs)

96

Shipping weight (kg)

43.6

Cooling method

Fan

UPS housing material

PVC

ENVIRONMENTAL

Operating Temperature Range

+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature Range

+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity

0 to 95%, non-condensing

AC mode BTU / hr. (full load)

82.4

Battery mode BTU / hr. (full load)

1219.3

AC mode efficiency rating (100%

load)

99%

COMMUNICATIONS

Communications interface

DB9 Serial; Contact closure

Network monitoring port description

Supports detailed monitoring of UPS and site power conditions; contact closure communications via two additional

DB9 ports (3 total)

PowerAlert software

Included

Communications cable

3 DB9 cables included

LINE / BATTERY TRANSFER

Transfer time

2-4 milliseconds

Low voltage transfer to battery

power (setpoint)

87

High voltage transfer to battery

power (setpoint)

140

SPECIAL FEATURES

Cold Start (startup in battery mode

during a power failure)

Cold-start operation supported

Green & high efficiency features

Individually controllable load banks

CERTIFICATIONS

UPS Certifications

Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category A (EMI)

WARRANTY

Product Warranty Period (Worldwide)

2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty.
