Dimensions in Inches (millimeters) are subject to change without notice.

www.glenair.com

E-Mail: sales@glenair.com

C-56

© 2013 Glenair, Inc.

U.S. CAGE Code 06324

Printed in U.S.A.

C

DIMENSIONS

Shell

Size

Ø A

J Flat

H Flat

B

Thread

K Thread

Ø N

ØP

In.

mm.

In.

mm.

In.

mm.

In.

mm.

In.

mm.

6

.455 11.56

.410 10.41

.595 15.11

.3750-.05P-.1L-2A .4375-28 UNEF-2A

.330

8.38 .236

5.99

7

.520 13.21

.536 13.61

.723 18.36

.4375-.05P-.1L-2A

.5625-32 UN-2A

.432 10.97 .324

8.23

8

.580 14.73

.536 13.61

.723 18.36

.5000-.05P-.1L-2A

.5625-32 UN-2A

.493 12.52 .390

9.91

9

.645 16.38

.596 15.14

.790 20.07

.5625-.05P-.1L-2A

.6250-28 UN-2A

.551 14.00 .444

11.28

10

.705

17.91

.658 16.71

.855 21.72

.6250-.05P-.1L-2A

.6875-28 UN-2A

.620 15.75 .520

13.21

11

.770 19.56

.718 18.24

.925 23.50

.6875-.05P-.1L-2A

.7500-28 UN-2A

.662 16.81 .557

14.15

13

.895 22.73

.845 21.46 1.044 26.52

.8125-.1P-.2L-2A

.8750-28 UN-2A

.703 17.86 .596

15.14

16

1.080 27.43 1.022 25.96 1.230 31.24

1.0000-.1P-.2L-2A

1.0625-20 UN-2A

.863 21.92 .756

19.20

17

1.145 29.08 1.096 27.84 1.290 32.77

1.0625-.1P-.2L-2A

1.1250-28 UN-2A

.912 23.16 .805

20.45

19

1.283 32.59 1.225 31.12 1.415 35.94

1.8750-.1P-.2L-2A

1.2500-28 UN-2A 1.018 25.86 .910

23.11

21

1.415 35.94 1.346 34.19 1.577 40.06

1.3125-.1P-.2L-2A

1.3750-28 UN-2A 1.170 29.72 1.061 26.95

KEY

POSITIONS

A°

B°

A

150°

210°

B

75°

210°

C

95°

230°

D

140°

275°

E

75°

275°

F

95°

210°

B°

A°

801-059-07

Series 801 Mighty Mouse Hermetic Receptacle

Quick Coupling, Jam Nut Mount with Co-Ax Pins

SERIES 801 JAM NUT PANEL CUTOUT

Shell

Size

L Flat

Ø M

In.

± .002

mm.

± 0.05

In.

mm.

6

.418/.414 10.62/10.52

.448 11.38

7

.544/.540 13.82/13.72

.573 14.55

8

.544/.540 13.82/13.72

.573 14.55

9

.604/.600 15.34/15.24

.635 16.13

10

.668/.664 16.97/16.87

.698 17.73

11

.728/.724 18.49/18.39

.760 19.30

13

.853/.849 21.67/21.56

.885 22.48

16

1.030/1.026 26.16/26.06 1.075 27.31

17

1.104/1.100 28.04/27.94 1.135 28.83

19

1.235/1.231 31.37/31.27 1.260 32.00

21

1.353/1.349 34.37/34.26 1.385 68.83

Recommended Panel

Cutout Shell Style -07

L Flat

Ø M

Jam Nut Mount Hermetic

801-059-07

5

4

3

2

1

J FLAT

H FLAT

2 PL

B THREAD

CO-AX PIN

Ø G

1.025

(26.04)

MAX

.335

Ø N

Ø P

4 X .025 H X .080 W

.100 MAX

PANEL

CABLE

ADAPTER

CRIMP

RING

SEE NOTE 3

.060
