Solder Mount Hermetic

801-059-03

DIMENSIONS

Shell

Size

Ø A

B

Thread

Ø N

Ø M

Panel

Cutout

In.

mm.

In.

mm.

In.

mm.

6

.455 11.56

.3750-.05P-.1L-2A

.330

8.38

.448 11.38

7

.520 13.21

.4375-.05P-.1L-2A

.432 10.97

.573 14.55

8

.580 14.73

.5000-.05P-.1L-2A

.493 12.52

.573 14.55

9

.645 16.38

.5625-.05P-.1L-2A

.551 14.00

.635 16.13

10

.705

17.91

.6250-.05P-.1L-2A

.620 15.75

.698 17.73

11

.770 19.56

.6875-.05P-.1L-2A

.662 16.81

.760 19.30

13

.895 22.73

.8125-.1P-.2L-2A

.703 17.86

.885 22.48

16

1.080 29.08

1.0000-.1P-.2L-2A

.863 21.92 1.075 27.31

17

1.145 29.08

1.0625-.1P-.2L-2A

.912 23.16 1.135 28.83

19

1.283 32.59

1.8750-.1P-.2L-2A

1.018 25.86 1.260 32.00

21

1.415 35.94

1.3125-.1P-.2L-2A

1.170 29.72 1.385 68.83

KEY

POSITIONS

A°

B°

A

150°

210°

B

75°

210°

C

95°

230°

D

140°

275°

E

75°

275°

F

95°

210°

B°

A°

A

.013

(0.33)

View A

For Size 6 Only

30°

1 2

3

4

5

1.025 (26.04)

Max

.039 (0.99)

Ø A

Ø N

B Thread

Co-Ax

Pin

.335 (8.51)

Cable

Adapter

Crimp

Ring

4 X .025 (0.64) H

X .080 (2.03) W

Ø P

See Note 3

801-059-03

Series 801 Mighty Mouse Hermetic Receptacle

Quick Coupling • Solder Mount • Co-Ax Pins

Connector Dimensions
